Effects Pedal - Reissue of the Classic Octave/Fuzz Pedal (sold by Fender from 1968-1977).

• Input Impedance: 82 kOhm
• Nominal Input Level: -20 dBV
• Output Impedance: 30 kOhm
• Nominal Output Level: -20 dBV
• Power Requirements: 9V DC (center pin = negative); 10 mA minimum
• Controls: Volume, Sustain, Tone, Blend
• On/Off footswitch
• Tone Boost footswitch
• True bypass circuitry
• 9V Power adapter jack
• Power supply: 9V battery, or optional mains adapter (not included)
• Extruded aluminum casing
• Germanium diodes
• Late '60s/'70s "F" knobs
• Easy access battery compartment
• Dimensions (HxWxD): ca. 2.25" (57mm) x 7.25" (184mm) x 4.75" (121mm)

Further information:

• Sustain Control - prolongs notes played through the effect by increasing the output boost as the input signal fades.
• Tone Control - shifts the tone balance from low frequencies at "1" to high frequencies at "10."
• Blend Control - Controls the output ratio of unprocessed signal mixed with Fender Blender processed signal.
• On/Off footswitch - switches the unit on-off.
• Tone Boost footswitch - Enhances the equalization of the Tone control.
